神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (55.100.DO[01]) - RELAY, BOX, ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
773 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN24E00016F3 | [1] | RELAY | KOB |
| 2. | YN73E01030P1 | [1] | LABEL | KOB |
| 3. | LS73E01011P1 | [1] | LABEL | KOB |
| 4. | YN24S00010P1 | [2] | RELAY | KOB(Used for Safety, Horn, Working Light, Travel Alarm, Cab Working Light, Auto Idle Stop, Eng Emerg Stop, Lever Lock, Alternator, Boom Light, Washer Motor, Wiper Motor) |
| 5. | LS73E01007P1 | [1] | DECAL | KOB |
