神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (55.101.AC[03]) - HARNESS, ASSY, UPPER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
719 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 71416130 | [3] | CLAMP,12mm, Coat, 12.5mm Bolt Hole, P Type | LEC Superseded by part number: 84553330 |
| 2. | 71405745 | [3] | CLAMP,18mm ID, 12.5mm Bolt Hole, P Type | LEC Superseded by part number: 84553276 |
| 3. | 71405770 | [1] | CLAMP,25mm ID, 15mm Bolt Hole, P Type | LEC Superseded by part number: 84551318 |
| 4. | 87526680 | [7] | RETAINER COLLAR | SM Superseded by part number: YN13E01375P1 |
| 5. | 14496531 | [5] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 6. | 16100821 | [1] | NUT,M8, Cl 10 | LEC Superseded by part number: 17037925 |
| 7. | 14496731 | [7] | WASHER,M12 x 24 x 2.5 Thk | LEC Superseded by part number: 895-11012 |
| 8. | 11112134 | [7] | SCREW | BRE Superseded by part number: 11112131 |
| 9. | 72951499 | [45] | CLIP | IMO Superseded by part number: PY01P01043D8 |
| 10. | 11195374 | [1] | LOCK WASHER | TOR Superseded by part number: 10571374 |
| 11. | 13272224 | [1] | SCREW,Cross Pan Hd, M4 x 16mm | LEC Superseded by part number: 13272214 |
| 12. | 87550878 | [1] | ELECTRIC CABLE | SMEngine |
