神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (55.101.AC[04]) - HARNESS, ASSY, UPPER, CAB Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
494 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN13E01733P1 | [1] | WIRE HARNESS | SM |
| 2. | LB13E01042P1 | [1] | WIRE HARNESS | SM |
| 3. | 11195474 | [12] | WASHER | HIT Superseded by part number: 11195471 |
| 4. | LB13E01040P1 | [1] | PLATE | KOB |
| 5. | LQ13E01215P1 | [1] | PLATE | SM |
| 6. | LQ13E01233P1 | [1] | GASKET | SM |
| 7. | 10977834 | [12] | BOLT,Hex, M5 x 16mm, Cl 10.9, Full Thd | HIT Superseded by part number: 10977831 |
| 8. | 87526680 | [14] | RETAINER COLLAR | SM Superseded by part number: YN13E01375P1 |
| 9. | 72951499 | [45] | CLIP | IMO Superseded by part number: PY01P01043D8 |
| 10. | 15903804 | [2] | SELF-TAP SCREW,Cross Pan Hd, M4.8 x 13mm | TTF |
| 11. | 16043231 | [1] | SCREW,Hex, M8 x 16mm, Cl 10.9, Full Thd | LEC |
| 12. | 14496531 | [1] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
