神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (84.100.AQ) - BUCKET, CYLINDER, ATTACHMENT PIN Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
915 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM12B01064P1 | [1] | PIN,70mm OD x 243mm L | KOB |
| 2. | ZN18C14011 | [2] | NUT | KOB |
| 3. | YT02B01008D1 | [1] | SHIM,0.5mm Thk | KOB120 X 72 X t0.5 |
| 4. | B16T0442D93 | [1] | SHIM,120mm OD x 72mm ID x 0.9mm Thk | KOB120 X 72 X t0.9 |
| 5. | YT02B01008D3 | [1] | SHIM,2.0mm Thk | KOB120 x 72 x t1.6 |
| 6. | YM12B01058D1 | [2] | SHIM | KOB120 x 72 x t2 |
| 7. | HS18C14130G1 | [1] | CAPSCREW,M14 x 130mm, Cl 10.9 | KOBSCREW M14 X 130 |
