神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (84.912.AA[03]) - ARM, ASSY (3.1M) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
314 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| .. | YM12BU0018F1 | [1] | ARM | KOBAssembly, Incl 1 - 18 |
| 3. | YM12BU0021P2 | [1] | ARM | KOBArm; Inc. 4 - 8 |
| 6. | YN12B02026P1 | [4] | BLOCK | KOB |
| 7. | YN43H01051P1 | [2] | BLOCK | KOB |
| 9. | YM12BU0022F1 | [1] | ARM | KOBArm; Inc.10 - 14 |
| 10. | YB12B01180P1 | [2] | BUSHING,80mm ID x 95mm OD x 84mm L | KOB |
| 11. | YM12BU0024P3 | [1] | ARM | KOBArm, Inc. 12 - 14 |
| 12. | YM12B01120P1 | [2] | BUSHING,65mm ID x 80mm OD x 69mm L | KOB |
| 13. | YM12B01135P1 | [2] | BUSHING,70.28mm ID x 85mm OD x 70mm L | KOB |
| 14. | YM12B01136P1 | [2] | BUSHING,80mm ID x 133mm OD x 80mm L | KOB |
| 15. | YM12BU0023P2 | [1] | ARM | KOBArm; Inc. 16 - 18 |
