神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (84.912.AA[02]) - ARM, ASSY (2.6M) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
737 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM12BU0026F1 | [1] | ARM | KOBAssembly, 2.6M |
| 1. | YM12BU0027P1 | [1] | ARM | KOBIncl 2 |
| 3. | YM12BU0029F1 | [1] | ARM | KOBArm 2.6M, Inc. 4 - 8 |
| 4. | YM12BU0033P1 | [1] | ARM | KOB |
| 6. | LC02B01024P1 | [2] | BLOCK | KOB |
| 7. | YN43H01051P1 | [2] | BLOCK | KOB |
| 9. | YM12BU0029F1 | [1] | ARM | KOBArm 2.6M, Inc. 10 - 14 |
| 10. | YB12B01180P1 | [1] | BUSHING,80mm ID x 95mm OD x 84mm L | KOB |
| 11. | YM12BU0030P2 | [2] | ARM | KOBArm 2.6M, Incl 12 - 14 |
| 12. | YM12B01120P1 | [4] | BUSHING,65mm ID x 80mm OD x 69mm L | KOB |
| 13. | YM12B01135P1 | [1] | BUSHING,70.28mm ID x 85mm OD x 70mm L | KOB |
| 14. | YM12B01136P1 | [1] | BUSHING,80mm ID x 133mm OD x 80mm L | KOB |
| 15. | YM12BU0031P1 | [1] | ARM | KOBArm 2.6M, Inc. 16 - 18 |
