神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (88.100.01[06]) - HYD. LINE, CONTROL, VALVE (N & B WITH FOOT CONTROL) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
302 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2444R963D20 | [1] | FLEXIBLE HOSE | KOB350 mm long (13-49/64 in) Superseded by part number: 77258641, HX31E04035DX |
| 2. | 2444Z3421 | [1] | TEE | KOB3/8PFx1/4PFx54mm Long (Incls. O-Ring ZD12P01400) |
| 2. | ZD12P01400 | [1] | O-RING | KOB(Part of 2444Z3421) ID 13.80 ? 0.19 x OD 18mm, Not Shown |
| 3. | HH25X04004G2 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 3. | ZD12P01100 | [1] | O-RING | KOB(Part of HH25X04004G2) ID 10.8mm x OD 13.2mm, Not Shown |
| 4. | LC52S00019P1 | [1] | SENSOR | SM(Low Pressure) (Used for Bucket, Boom Up/Down, Swing LH/RH, Arm In/Out, Travel LH/RH, P1/P2 Option, Dozer, N&B Revolution, Boom Rod Press, Boom Overload Alarm, Auto Accel, Option Selector Detect) (Incls. O-Ring ZD12P01100) |
| 4. | ZD12P01100 | [1] | O-RING | KOB(Part of LC52S00019P1) ID 10.8mm x OD 13.2mm, Not Shown |
| 5. | 2444Z2894 | [1] | 90 ELBOW | KOB1/4 PF (Incls. O-Ring ZD12P01100) |
| 5. | ZD12P01100 | [1] | O-RING | KOB(Part of 2444Z2894) ID 10.8mm x OD 13.2mm, Not Shown |
