神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (88.100.01[07]) - HYD. LINE, CONTROL BLOCK (N & B WITH FOOT CONTROL) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
806 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87338537 | [1] | HYDRAULIC HOSE,6.35 mm ID x 1000.00 mm | SM(2420R349D100) Superseded by part number: HX21E04100DX |
| 2. | 87605018 | [1] | HYDRAULIC HOSE,6.35 mm ID x 1800.00 mm | SM(2420R349D180) Superseded by part number: 2420R349D180 |
| 3. | 72214522 | [1] | HYD CONNECTOR | SM(ZH22X04006) Superseded by part number: ZH22X04006 |
| 4. | 72214561 | [1] | HYD CONNECTOR | SM(ZH42X04006) Superseded by part number: ZH42X04006 |
