神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (88.100.02[02]) - VALVE, SELECTOR (N & B WITH HAND CONTROL) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
263 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YB30V00018F1 | [1] | CONTROL VALVE | KOBOpt Selector, Incl in 2 - 11 |
| 2. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOB |
| 3. | ZD12P00900 | [1] | O-RING | KOB |
| 4. | YB30V00018S201 | [1] | COVER | SM Superseded by part number: YB30V00018F1 |
| 5. | YB30V00018S301 | [1] | COIL | SMSpool Superseded by part number: YB30V00018F1 |
| 6. | YB30V00018S321 | [1] | SPRING | SM Superseded by part number: YB30V00018F1 |
| 7. | YN35V00050F1 | [1] | SOLENOID VALVE,Cartridge W/Coil | KOBAttachment Boost, Travel 1, 2 Speed, Lever Lock, Solenoid Superseded by part number: YN35V00061F1 |
| 8. | ZS23C08025 | [2] | SCREW,Hex Socket Head, M8 x 25mm | KOBCap |
| 9. | YN35V00047S171 | [2] | SCREW,Hex Socket Head, M5 x 12mm | SMCap Superseded by part number: ZS23C05012 |
| 10. | ZS23C12085 | [3] | SCREW,Hex Socket Head, M12 x 85mm | KOBCap |
| 11. | ZS23C12060 | [1] | SCREW,Hex Socket Head, M12 x 60mm | KOBCap |
