神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (88.100.02[03]) - SOLENOID VALVE (N & B WITH HAND CONTROL) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
1003 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN35V00050F1 | [1] | SOLENOID VALVE,Cartridge W/Coil | KOBAssembly, Solenoid, Incl 2 - 6 Superseded by part number: YN35V00061F1 |
| 2. | YN35V00004S361 | [1] | O-RING | KOB |
| 3. | YN35V00004S362 | [1] | O-RING | KOB |
| 4. | YN35V00004S363 | [1] | O-RING | KOB |
| 5. | YN35V00018S802 | [1] | NUT | KOB |
| 6. | ZD12P02000 | [1] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOB |
