神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (88.100.02[08]) - CONTROL, LINE, VALVE (N & B WITH HAND CONTROL) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
645 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 72214543 | [1] | HOSE | SM Superseded by part number: 24820R63D115 |
| 2. | 87536897 | [1] | FLEXIBLE HOSE | SM Superseded by part number: 2420R349D210 |
| 3. | 87336044 | [1] | HYDRAULIC HOSE,6.35 mm ID x 3600.00 mm | IMO Superseded by part number: HX21E04360DX |
| 4. | 72214522 | [1] | HYD CONNECTOR | SM Superseded by part number: ZH22X04006 |
| 5. | 72214561 | [1] | HYD CONNECTOR | SM Superseded by part number: ZH42X04006 |
| 6. | 72214525 | [1] | 90 ELBOW | SM(ZH32X04006) Superseded by part number: ZH32X04006 |
| 7. | 72283559 | [1] | TEE | IMO Superseded by part number: HH55Q06006G1 |
| 8. | 72951499 | [1] | CLIP | IMO Superseded by part number: PY01P01043D8 |
