神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (88.100.03[02]) - CONTROL VALVE ASSY (ROTATION) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
770 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87386068 | [1] | HYDRAULIC VALVE | SMAssembly (YN30V00107F1) Incl 101 to 702 |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONBody |
| 111. | NSS | [1] | NOT SOLD SEPARAT | CONBody |
| 121. | YN30V00108S121 | [1] | PLATE | SM |
| 151. | 72209842 | [1] | PLUG | SM(2436U1832S651) Superseded by part number: 2436U1832S651 |
| 152. | YN30V00107S152 | [1] | PLUG | SM |
| 153. | 72209815 | [1] | PLUG | IMO(2441U722S490) Superseded by part number: 2441U722S490 |
| 161. | 72209823 | [2] | O-RING | IMO(ZD12P01600) Superseded by part number: ZD12P01600 |
| 162. | 71404166 | [1] | O-RING,2.4mm Thk x 17.8mm ID, 90 Duro | LEC(ZD12P01800) |
| 163. | 72209824 | [2] | O-RING | IMO(ZD12P02000) Superseded by part number: ZD12P02000 |
| 164. | 72210077 | [6] | O-RING | IMO(ZD12P01500) Superseded by part number: ZD12P01500 |
| 201. | NSS | [1] | NOT SOLD SEPARAT | CONCover |
| 261. | YN30V00108S261 | [2] | O-RING | SM Superseded by part number: ZD12A02100 |
| 271. | YN35V00017S171 | [8] | SCREW,Hex Socket Head, M5 x 16mm | KOB Superseded by part number: ZS23C05016 |
| 321. | YN30V00107S321 | [1] | SPRING | SM |
| 322. | EM30V00001S321 | [2] | SPRING | SM |
| 331. | YA30V00002S331 | [2] | SEAL | SM |
| 332. | YA30V00002S332 | [2] | SEAT/SLOT | SM |
| 511. | YA30V00002S511 | [1] | VALVE POPPET | SM |
| 521. | YA30V00002S521 | [1] | SPRING | SM |
| 551. | YA30V00002S551 | [1] | PLUG | SM |
| 601. | YN22V00040F2 | [1] | HYDRAULIC VALVE | SMAssembly |
| 602. | YN22V00041F2 | [2] | HYDRAULIC VALVE | SMAssy, Contains 602A |
| 602A. | 72209824 | [1] | O-RING | IMO Superseded by part number: ZD12P02000 |
| 701. | 14311070 | [4] | SCREW,Hex Socket Head, M12 x 52mm | SMM12x25 Superseded by part number: ZS23C12025 |
| 702. | 14359570 | [4] | HEX SOC SCREW,M8 x 1.25 x 80mm, Cl 12.9 | COEM8x80 12.9 |
