神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (88.100.03[03]) - HYD. LINE, UPPER (ROTATION) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
232 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LQ03HU1003P1 | [1] | TUBE | KOBTUBE |
| 2. | LQ03HU1004P1 | [1] | TUBE | KOBTUBE |
| 3. | LQ03HU1005P1 | [1] | BRACKET | KOBSUPPORT |
| 4. | ZC27X28012 | [2] | CLAMP | KOB Superseded by part number: YN43H01097P1 |
| 5. | 2444T2958 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| 6. | ZA38F22008 | [2] | HYD CONNECTOR | SMElbow, 90? -- 1/2 PF - M30x1.50x45mm Long (No O-Ring supplied) |
| 7. | ZM73C12025 | [2] | BOLT,M12x25mm - Course Thread | KOBM12x1.75x25mm (Incls. Washer) |
| 8. | ZS18C10060 | [2] | SCREW,Hex, M10 x 60mm | KOBM10x1.50x60mm |
| 9. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 10. | ZN18C10008 | [2] | NUT | KOBM10x1.50mm |
| 11. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 12. | NA | [1] | NOT SERVICED | FOR |
| 13. | NA | [1] | NOT SERVICED | FOR |
| . . | 2444Z2870D1 | [2] | HYD CONNECTOR | KOBNot Shown, Part Of 6 and 11 |
