神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (88.100.03[06]) - SOLENOID VALVE, ASSY (ROTATION) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
961 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | PW35V00002F1 | [1] | SOLENOID VALVE | KOBValve Assy, Incl 2 - 4 |
| 2. | PW35V00002S101 | [1] | BODY | KOB |
| 3. | YN35V00047S171 | [4] | SCREW,Hex Socket Head, M5 x 12mm | SMCap Superseded by part number: ZS23C05012 |
| 4. | PW35V00003F1 | [2] | SOLENOID VALVE | SMSolenoid, Incl 5 - 9 |
| 5. | YN35V00004S361 | [1] | O-RING | KOB |
| 6. | YN35V00004S362 | [1] | O-RING | KOB |
| 7. | YN35V00004S363 | [1] | O-RING | KOB |
| 8. | YN35V00018S802 | [1] | NUT | KOB |
| 9. | ZD12P02000 | [1] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOB |
