神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (88.100.03[07]) - SOLENOID VALVE, ASSY (ROTATION) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
274 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | 72955526 | [1] | VALVE | KOBAssembly, Solenoid (YN35V00010F2) Superseded by part number: YN35V00010F2 |
| 1. | 72215300 | [1] | PLUG | IMO(2436U2159S3) Superseded by part number: 2436U2159S3 |
| 2. | 72150613 | [1] | BODY | IMO(YN35V00010S002) Superseded by part number: YN35V00010S002 |
| 3. | 72210447 | [1] | SPRING | IMO(2436U2802S3) Superseded by part number: 2436U2802S3 |
| 4. | 72150614 | [1] | SPOOL | IMO(YN35V00010S004) |
| 8. | 72215301 | [2] | SCREW | IMO(EN35V00004S010) M05x0.8x10mm Superseded by part number: EN35V00004S010 |
| 10. | 72210491 | [1] | O-RING | IMO(ZD11P01000) ID 9.8 ± 0.17 x OD 13.6mm Superseded by part number: ZD11P01000 |
| 11. | 72210450 | [1] | O-RING | IMO(ZD11P01600) ID 15.80 ± 0.20 x OD 20.6mm Superseded by part number: ZD11P01600 |
| 12. | 72210451 | [1] | HYDRAULIC VALVE | SM(YR35V00009S022) Superseded by part number: YR35V00009S022 |
