神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (88.100.12[01]) - HYD. LINE, CYLINDER (LOAD HOLDING VALVE) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
258 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM42H01032P1 | [1] | RIGID TUBE | KOB |
| 2. | YM42H01033P1 | [1] | RIGID TUBE | KOB |
| 3. | YM42H01034P1 | [1] | RIGID TUBE | KOB |
| 4. | YM42H01035P1 | [1] | TUBE | KOB |
| 5. | ZX20H10074 | [4] | HOSE | KOB |
| 6. | 2432T2242 | [2] | CLAMP | KOB |
| 7. | ZS18C12050 | [2] | SCREW,Hex, M12 x 50mm | KOB |
| 8. | ZS28C10030 | [16] | SCREW,Hex Socket Head, M10 x 30mm | KOB |
| 9. | ZW26X12000 | [2] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 10. | ZH22Z04000 | [2] | HYD CONNECTOR | KOB |
| 11. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8 PT -- Straight |
| 12. | ZD12P02600 | [4] | O-RING | KOB |
| 13. | ZD12A01600 | [4] | O-RING | KOB |
| 14. | YM42HU1014P1 | [2] | BAND | KOB |
| 15. | YM42HU1015P1 | [2] | BAND | KOB |
| 16. | ZS18C10030 | [2] | SCREW,Hex, M10 x 30mm | KOB |
| 17. | ZW26X10000 | [2] | LOCK WASHER | KOB |
