现代零件查询50/60/70D-7A REMOTE CONTROL VALVE(5-SPOOL,OLD)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
692 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
34FT-06010
|
[1] |
RCV
|
|
| . |
34FT-06010
|
[1] |
RCV
|
|
| 1. |
XKCK-00046
|
[5] |
BODY & PLUG
|
|
| 2. |
XKCK-00045
|
[10] |
SPOOL
|
|
| 3. |
XKCK-00044
|
[10] |
STOPPER-SPOOL
|
|
| 4. |
XKCK-00043
|
[10] |
SEAT-SPRING
|
|
| 5. |
XKCK-00042
|
[10] |
SHIM
|
|
| 6. |
XKCK-00041
|
[10] |
SPRING-RETURN
|
|
| 7. |
XKCK-00040
|
[10] |
SPRING-PR
|
|
| 8. |
XKCK-00039
|
[10] |
PLUNGER & SLEEVE
|
|
| 9. |
XKCK-00038
|
[8] |
O-RING
|
|
| 10. |
XKCK-00037
|
[2] |
PLUG & O-RING
|
|
| 11. |
XKCK-00036
|
[5] |
BRACKET
|
|
| 12. |
XKCK-00035
|
[5] |
HINGE ASSY
|
|
| 13. |
XKCK-00034
|
[5] |
RUBBER BELLOWS
|
|
| 14. |
XKCK-00030
|
[2] |
TIE BOLT
|
|
| 15. |
XKCK-00029
|
[4] |
NUT
|
|
| 17. |
XKCK-00028
|
[20] |
BOLT
|
|
| S1. |
XKCK-00047
|
[1] |
SECTION ASSY 1
|
|
| S2. |
XKCK-00048
|
[3] |
SECTION ASSY 2
|
|
| S3. |
XKCK-00049
|
[1] |
SECTION ASSY 3
|
|
| K9. |
XKCK-00050
|
[10] |
SPOOL KIT
|
|
| K4. |
XKCK-00020
|
[1] |
TIE BOLT & NUT-KIT
|
|
| K8. |
XKCK-00016
|
[8] |
SEAL-KIT
|
|
