神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (90.108.AB[01]) - DECALS, EXTERIOR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
342 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM20TU0001P1 | [2] | DECAL | KOB |
| 2. | LC20TU1055P1 | [1] | LABEL | KOB |
| 3. | LC20TU1056P1 | [1] | LABEL | KOB |
| 4. | LC22T00137P1 | [2] | DECAL | KOB |
| 5. | YN20T02291P1 | [1] | LABEL | KOB |
| 6. | LC20TU1058P1 | [1] | LABEL | KOB |
| 7. | LC20TU1059P1 | [1] | LABEL | KOB |
| 8. | LC20TU1060P1 | [1] | LABEL | KOB |
| 9. | YN20TU1299P1 | [2] | DECAL | KOB |
| 10. | LB22T01004P1 | [1] | DECAL | SM |
| 11. | 71433122 | [2] | WARNING DECAL | LEC(YN20T01973P1) |
| 12. | YN22T00244P1 | [2] | TYPE PLATE | KOB |
| 13. | YN20T01337P1 | [2] | LABEL | KOB |
