神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (88.100.AE[02]) - SUN VISOR, LIGHT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
405 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| .. | YN32T02529F1 | [1] | KIT | KOBDIA, Lights and Rainguard, Incl 1 - 5 and Fig 88.100.AE(01) 1 - 13 Superseded by part number: 87015736, 2420R372D7, 84563611, LC55C01001P1, YN50S00040D4, 12654421, LQ80E01019P2, YN55C01025P1, 16043231, 71450974, LQ55C01027P1, YN24S00010P1, LQ55C01013P1, LQ55C01002F1, LC55C01004P1, 895-11012, YT50C01020P1 |
| 1. | LQ80E01019P1 | [2] | WIRE HARNESS | SMCab Rainguard Lights Superseded by part number: LQ80E01019P2 |
| 2. | 87555081 | [2] | HEADLAMP | SMIncl 3 Superseded by part number: 84563611 |
| 3. | 71450974 | [1] | BULB | TOR |
| 4. | 87559198 | [1] | LIGHT SWITCH | SM(YN50S00040D4) Superseded by part number: YN50S00040D4 |
| 5. | 87559156 | [1] | RELAY | SM(YN24S00010P1) Superseded by part number: YN24S00010P1 |
