神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (90.110.BC) - CAB FLOOR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
454 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN03M02125P1 | [2] | INSULATOR BLOCK | SMRUBBER |
| 2. | 11106634 | [16] | BOLT,Hex, M10 x 35mm, Cl 10.9, Full Thd | LEC(ZM22C10035) M10x1.50x35mm (Incls. Washer & Lockwasher) Superseded by part number: 86624978 |
| 3. | 71405003 | [4] | WASHER | TOR(ZW16H16000) ID 17 x OD 32 x Th 4.5mm Superseded by part number: 98416514 |
| 4. | 12163321 | [4] | NUT,M16, Cl 10 | IMO(ZN18C16013 ) M16x2.0mm Superseded by part number: |
| 5. | YN03M02126P1 | [2] | INSULATOR BLOCK | SM |
| 6. | LB03M01007P1 | [1] | FOOT BOARD | SM |
| 7. | 14496631 | [16] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LECM10 X 21 X 2 (ZW16X10000) Superseded by part number: 14496621 |
| 8. | 10516874 | [16] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | TTF(ZW26X10000) ID 10 x OD 18 x Th 2.5mm Superseded by part number: 140028 |
| 9. | LB03M01015P1 | [1] | DECAL | SM |
