神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (90.119.AA[02]) - GUARD INSTALL (BONNET) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
726 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YB22C01059F1 | [1] | COVER | KOBAssembly, Incl 2 - 14 |
| 2. | YB22C01057P1 | [1] | COWLING | SMIncl 3 - 4 Superseded by part number: YB22C01057P2 |
| 3. | LC22C01028P1 | [2] | HINGE | KOB |
| 4. | ZS11C12030 | [4] | CAP,Hex, M12 x 30mm, Cl 4.8 | KOBScrew -- M12x1.75x30mm Superseded by part number: ZM12C12030 |
| 5. | YB22C01060P1 | [1] | FOAM INSULATION | KOBInsulation |
| 6. | YB22C01062P1 | [2] | FOAM INSULATION | KOBInsulation |
| 7. | YN22C01283D1 | [1] | WEATHERSTRIP | KOB |
| 8. | YR21C01251D4 | [1] | WEATHERSTRIP | KOB |
| 9. | 2416T13435 | [2] | RUBBER | KOB |
| 10. | 2406Z304 | [1] | HANDLE | KOB |
| 11. | YN22C01297P1 | [2] | FOAM INSULATION | KOB |
| 12. | YN22C01287P1 | [1] | PLATE | KOB |
| 13. | ZM73C08020 | [4] | BOLT,M8x20mm - Course Thread | KOBM08x1.25x20mm (Incls. Washer) |
| 14. | ZW16H08000 | [4] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 15. | LC21C01811P2 | [1] | LATCH | SM(Supplied with Key); Replacement keys are not available |
| 16. | LC21C01812P2 | [1] | HANDLE | SM(Non-locking) Superseded by part number: LC21C01811P2 |
| 17. | 2418T10357 | [4] | WASHER | KOBID 13 x OD 30 x Th 3.2mm Superseded by part number: 2418T12345 |
| 18. | ZN18C08007 | [4] | NUT | KOBM08x1.25mm |
| 19. | ZN18C12010 | [4] | NUT | KOBM12x1.75mm |
| 20. | ZM73C08025 | [8] | BOLT,M8x25mm - Course Thread | KOBM08x1.25x25mm (Incls. Washer) |
| 21. | ZW16H08000 | [12] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
