神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (90.119.AB[07]) - GUARD INSTALL (PARTITION) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
128 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONGuard Assembly Incl 2 -5 |
| 2. | YM21C01332P1 | [1] | GUARD | KOBGuard |
| 3. | YN21C03244P2 | [1] | FOAM INSULATION | KOB |
| 4. | LB21C01277P1 | [1] | INSULATION | KOB |
| 5. | YN21C03767P1 | [1] | RUBBER BUSHING | KOB |
| 6. | YM21C01325P1 | [1] | GUARD | SMAssembly, Incl 7 - 9 |
| 6. | YB21C01566P1 | [1] | GUARD | KOB Superseded by part number: YM21C01325P1 |
| 7. | YM21C01326P1 | [1] | INSULATION | KOB |
| 8. | YM21C01327P1 | [1] | INSULATION | KOB |
| 9. | YM21C01330P1 | [1] | INSULATION | KOB |
| 10. | YB21C01531F1 | [1] | GUARD | SMAssembly, Incl 11 - 13 |
| 11. | 87362136 | [1] | WEATHERSTRIP | KOB(YB21C01256P1) L=320 Superseded by part number: YB21C01256P1 |
| 12. | 87362138 | [1] | WEATHERSTRIP | KOB(YB21C01258P1) L=233 Superseded by part number: YB21C01258P1 |
| 13. | 87362140 | [1] | INSULATION | KOBInsulation (YB21C1259P1) Superseded by part number: YB21C01259P1 |
| 14. | YN21C02138P1 | [3] | WASHER | KOB |
| 15. | YN21C02147P1 | [3] | WASHER | KOB |
| 16. | ZS18C12025 | [12] | SCREW,Hex, M12 x 25mm | KOB |
| 17. | 2418T10357 | [14] | WASHER | KOB Superseded by part number: 2418T12345 |
| 18. | ZS18C12030 | [2] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
