神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (90.160.AF[06]) - CLAMP, ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
504 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN12P01205F1 | [1] | CLAMP | SMClamp Assembly |
| 1. | YN26M00076P1 | [1] | CARPET | SMFloor Mat |
| 2. | 87746013 | [2] | PLATE | SM(YY55M01009P1) |
| 3. | 11106034 | [4] | BOLT,Hex, M10 x 20, 10.9, Full Thd | BURSems (ZM73C10020) Superseded by part number: 11106031 |
| 4. | 16043434 | [4] | BOLT,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd | LECSems (ZM73C08020) Superseded by part number: 16043431 |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONClamp Assembly, Part of YN12P01205F1 |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONClamp Assembly, Part of YN12P01205F1, Inc. 7-8 |
| 7. | YN12P01206P1 | [1] | CLAMP | KOB |
| 8. | YN12P01166P1 | [1] | RUBBER SEAL | KOB |
| 9. | 87528679 | [1] | BRACKET | SM(YN12P01173F1) Inc. 10-11 Superseded by part number: YN12P01173F1 |
| 10. | YN12P01177P1 | [1] | PLATE | KOB(87528681) |
| 11. | YN12P01175P1 | [1] | FLEXIBLE HOSE | KOBRubber (87528686) |
| 12. | 87528672 | [2] | BRACKET | SM(YN12P01164F1) Superseded by part number: YN12P01164F1 |
| 13. | YN12P01165P1 | [1] | PLATE | KOB |
| 14. | YN12P01166P1 | [1] | RUBBER SEAL | KOB |
| 15. | 14305334 | [4] | HEX SOC SCREW,M6 x 20mm, Cl 10.9, Full Thd | LECCap (ZS28C06020) Superseded by part number: 14305324 |
| 16. | 10516474 | [4] | LOCK WASHER | LEC(ZW26K06000) Superseded by part number: 10516471 |
