神钢零件查询(SK170 ACERA M-9) - CRAWLER EXCAVATOR - TIER 3 NON-REGULATED (1/12-12/13) (90.160.AF[03]) - CONTROL, OPERATOR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
582 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN03M00304F1 | [1] | CONTROL | SMControl Box Assembly, Incl 2 - 12 |
| 2. | YN03M02165P1 | [1] | BRACKET | KOBAssembly |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONControl Box |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONControl Box |
| 5. | YN03M02168P1 | [1] | LEVER ASSY & KNOB | KOB |
| 6. | YN03M02169P1 | [1] | COVER | KOB |
| 7. | YN03M02202P1 | [8] | SCREW,Hex Socket Head, M10 x 25mm | KOB Superseded by part number: ZS28C10025 |
| 8. | YN03M02204P1 | [10] | LOCK WASHER | KOB Superseded by part number: ZW26X10000 |
| 9. | YN03M02205P1 | [2] | SCREW | KOB Superseded by part number: ZS18C10025 |
| 10. | YN03M02211P1 | [2] | SCREW,Hex Socket Head, M8 x 25mm | KOB Superseded by part number: ZS28C08025 |
| 11. | YN03M02209P1 | [2] | LOCK WASHER | KOB Superseded by part number: 83990583 |
| 12. | YN50S00055F1 | [1] | SWITCH ASSY | KOBLever Lock (3 prong switch) |
