神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (04-07[00]) - HYD LINES, BOOM (BASE + STD) (YM42HU0008F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
914 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM42H01032P1 | [1] | RIGID TUBE | KOB970mm Long (38-3/16 in) |
| 2. | YM42H01033P1 | [1] | RIGID TUBE | KOB970mm Long (38-3/16 in) |
| 3. | YM42H01034P1 | [1] | RIGID TUBE | KOB580mm Long (22-27/32 in) |
| 4. | YM42H01035P1 | [1] | TUBE | KOB384mm Long (15-7/64 in) |
| 5. | ZX20H10074 | [4] | HOSE | KOB740mm Long (29-1/8 in) |
| 6. | 2432T2242 | [2] | CLAMP | KOBDouble -- 106x38x12mm (Ø23xØ29mm) |
| 7. | ZS18C12050 | [2] | SCREW,Hex, M12 x 50mm | KOBM12x1.75x50mm |
| 8. | ZS28C10030 | [16] | SCREW,Hex Socket Head, M10 x 30mm | KOBM10x1.50x30mm |
| 9. | ZW26X12000 | [2] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 10. | ZH22Z04000 | [2] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 11. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 12. | ZD12P02600 | [4] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 13. | ZD12A01600 | [4] | O-RING | KOBID 15.60 ± 0.12 x OD 19.16mm |
| 14. | YM42HU1014P1 | [2] | BAND | KOB |
| 15. | YM42HU1015P1 | [2] | BAND | KOB |
| 16. | ZS18C10030 | [4] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 17. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
