神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (04-10[00]) - ARM (3.10M), (YM12BU0018F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
499 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM12BU0024P2 | [1] | Arm | |
| 2. | YM12B01135P1 | [2] | BUSHING,70.28mm ID x 85mm OD x 70mm L | KOBID 70.2 x OD 85 x 70mm Long |
| 3. | YM12B01092P1 | [2] | BUSHING | KOBID 65.2 x OD 80 x 68mm Long |
| 4. | YN12B01596P1 | [2] | BUSHING | KOBID 80 x OD 95 x 82mm Long Superseded by part number: YN12B01839P1 |
| 5. | YM12B01136P1 | [2] | BUSHING,80mm ID x 133mm OD x 80mm L | KOBID 85 x OD 100 x 74mm Long, Flanged |
| 6. | YN43H01051P1 | [2] | BLOCK | KOB |
| 7. | YN12B02026P1 | [4] | BLOCK | KOB |
| 8. | YM12BU0023P2 | [1] | ARM | KOBArm |
