神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (04-16[00]) - BOOM GROUP - LUBRICATION Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
941 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2444R1117D505 | [1] | FLEXIBLE HOSE,6.40mm ID x 5050mm L | KOB5050mm Long |
| 2. | 2444R1117D425 | [2] | FLEXIBLE HOSE,6.40mm ID x 4250mm L | KOB |
| 3. | 2444R1117D245 | [2] | HOSE,6.40mm ID x 2450mm L | KOB Superseded by part number: HX21E04245DY |
| 4. | ZS18C10040 | [2] | SCREW,Hex, M10 x 40mm | KOB |
| 5. | ZW16H10000 | [2] | WASHER | KOB |
| 6. | YN02BU1011P1 | [1] | SUPPORT | KOB |
| 7. | ZG91S02000 | [10] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 8. | ZH32Z04000 | [2] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| 10. | 2445R220D17 | [2] | SEAL,85mm ID x 100mm OD x 6mm Thk | KOBNot Shown Superseded by part number: 160484A1 |
