神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (08-01-01[01]) - VALVE ASSY, CONTROL (YM30V00011F1) PAGE 1 OF 9 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
877 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM30V00011F1 | [1] | CONTROL VALVE | KOBAssembly Incls. Figures (08-01-01) - (08-01-09) Superseded by part number: YM30V00011F2 |
| 155. | YW30V00001S155 | [4] | PLUG | KOB1/2" |
| 161. | ZD12G03000 | [13] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 163. | ZD12P01800 | [4] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 164. | ZD12P01500 | [4] | O-RING | KOBID 14.80 ± 0.20 x OD 19mm |
| 166. | ZD12P01000 | [7] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm |
| 207. | YM30V00008S207 | [1] | GUARD | SMCover |
| 266. | ZD12P00700 | [4] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring -- ID 06.80 ± 0.16 x OD 10mm |
| 267. | ZD12P03200 | [2] | O-RING | KOBID 31.70 ± 0.31 x OD 38mm |
| 278. | ZS23C06030 | [5] | SCREW,Hex Socket Head, M6 x 30mm | KOBM06x1.0x30mm |
| 517. | YM30V00008S517 | [1] | POPPET | SM |
| 518. | YM30V00008S518 | [1] | POPPET | SM |
| 527. | YM30V00008S527 | [1] | SPRING | SM |
| 528. | YM30V00008S528 | [1] | SPRING | SM |
