神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (08-03[00]) - VALVE ASSY, CONTROL (YB30V00018F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
669 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB30V00018F1 | [1] | CONTROL VALVE | KOBAssembly |
| 161. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 162. | ZD12P00900 | [1] | O-RING | KOBID 08.80 ± 0.17 x OD 12mm |
| 201. | YB30V00018S201 | [1] | COVER | SM Superseded by part number: YB30V00018F1 |
| 301. | YB30V00018S301 | [1] | COIL | SMSpool Superseded by part number: YB30V00018F1 |
| 321. | YB30V00018S321 | [1] | SPRING | SM Superseded by part number: YB30V00018F1 |
| 601. | YN35V00050F1 | [1] | SOLENOID VALVE,Cartridge W/Coil | KOBSee Figure 08-03-01 Superseded by part number: YN35V00061F1 |
| 701. | ZS23C08025 | [2] | SCREW,Hex Socket Head, M8 x 25mm | KOBM08x1.25x25mm |
| 702. | YN35V00047S171 | [2] | SCREW,Hex Socket Head, M5 x 12mm | SMM05x0.8mm Superseded by part number: ZS23C05012 |
| 703. | ZS23C12085 | [3] | SCREW,Hex Socket Head, M12 x 85mm | KOBM12x1.75x85mm |
| 704. | ZS23C12060 | [1] | SCREW,Hex Socket Head, M12 x 60mm | KOBM12x1.75x60mm |
