神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (08-14-05[00]) - HYDRAULIC PUMP - COMPONENTS (YX10V00004F3) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
258 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YX10V00004F3 | [1] | HYDRAULIC PUMP | SM |
| 10. | NA | [1] | NOT SERVICED | FORPoppet |
| 11. | NA | [1] | NOT SERVICED | FORSeat |
| 12. | YN10V00014S012 | [1] | RING | KOB |
| 13. | YN10V00014S013 | [1] | SPRING | KOB |
| 14. | YN10V00014S014 | [1] | SCREW | KOB |
| 15. | NA | [1] | NOT SERVICED | FORBody |
| 312. | YN10V00006S312 | [1] | LOCK NUT | KOBM14x1.50mm |
| 353. | NA | [1] | NOT SERVICED | FORGear |
| 354. | NA | [1] | NOT SERVICED | FORGear |
| 355. | YN10V00006S355 | [1] | FILTER | KOBFilter |
| 361. | NA | [1] | NOT SERVICED | FORBody |
| 433. | YN10V00006S433 | [2] | SOCKET | KOBM08 |
| 434. | YN10V00006S434 | [2] | SOCKET | KOBM08 |
| 435. | YN10V00014S435 | [4] | BOLT | KOBM10 |
| 466. | 2441U667S466 | [1] | PLUG | KOB1/4" PF |
| 700. | YN10V00006S700 | [1] | RING | KOB |
| 710. | ZD12G09500 | [1] | O-RING,3.1mm Thk x 94.4mm ID, 90 Duro | KOBO-Ring -- ID 94.40 ± 0.81 x OD 100mm |
| 725. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 732. | ZD12P01600 | [1] | O-RING | KOBID 15.80 ± 0.20 x OD 20mm |
| 850. | ZR26X01800 | [1] | RING | KOBRetaining -- ID 18 x OD 19.5 x Th 1.0mm |
| 860. | YN10V00033R100 | [1] | SHAFT, PLANETARY CAR | KOBContains Items 10, 11, 15, 353, 354 & 361 |
