神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (08-14-06[00]) - CASE ASSY, GEAR (YB46W00001F2) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
818 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB46W00001F2 | [1] | GEAR | KOBCase Assembly (Use oring ZD12G09500 at attach point) |
| 1. | ZP26D04020 | [1] | ROLL PIN | KOBOD 04 x 20mm Long |
| 2. | ZS23C10020 | [2] | SCREW,Hex Socket Head, M10 x 20mm | KOBM10x1.50x20mm |
| 3. | YX46W00001S435 | [4] | SOCKET | KOBCap Screw |
| 4. | 2441U436S469 | [1] | PLUG | KOB |
| 5. | ZD12G08500 | [1] | O-RING,84.40mm ID x 90.60mm OD x 3.10mm | KOBID 84.40 ± 0.73 x OD 90mm |
| 6. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
