神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (08-27[00]) - VALVE ASSEMBLY, RELIEF (YN22V00014F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
623 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN22V00014F1 | [1] | VALVE | KOBRelief Assembly |
| 101. | NA | [1] | NOT SERVICED | FORBody |
| 161. | ZD12G03000 | [1] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 201. | NA | [1] | NOT SERVICED | FORPlug |
| 261. | NA | [1] | NOT SERVICED | FORO-Ring |
| 301. | NA | [1] | NOT SERVICED | FORPiston |
| 302. | NA | [1] | NOT SERVICED | FORPiston |
| 321. | NA | [1] | NOT SERVICED | FORSpring |
| 331. | NA | [1] | NOT SERVICED | FORSeat |
| 341. | NA | [1] | NOT SERVICED | FORSeat |
| 342. | NA | [1] | NOT SERVICED | FORSleeve |
| 401. | NA | [1] | NOT SERVICED | FORPlug |
| 461. | NA | [1] | NOT SERVICED | FORO-ring |
| 471. | NA | [1] | NOT SERVICED | FORNut |
