神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (09-09[00]) - BREATHER - ENGINE (101580150001) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
462 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2852684 | [1] | BREATHER | TOR Superseded by part number: 504069559 |
| 2. | 2852028 | [1] | GASKET,86mm ID x 94.6mm OD x 8.6mm Thk | TOR Superseded by part number: 500315795 |
| 3. | 4899110 | [3] | SCREW,Hex Flg, M6 x 1 x 20 | TORM06x1.0x20mm, Alternate, Serial Range: Part-4899092 |
| 3. | 4899092 | [3] | SCREW,Hex Flg, M6 x 1 x 25 | TORAlternate Part to 4899110, M06x1.0x25mm |
| 4. | REF | [1] | INSTRUCTION | NHCover -- See Figure 09-12 |
