神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (09-18[00]) - CONNECTING ROD (101580510010) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
788 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2831298 | [4] | CONNECTING ROD | TOR |
| . . | 2831298R | [4] | REMAN-CONNECTING ROD | TORSK170-8 Acera Mark VIII Tier 3 (5/07). |
| . . | 2831298C | [1] | CORE-ROD CONNECTING | TORReturn Number |
| 2. | 4892708 | [1] | BUSHING,38.02mm ID x 41.01mm OD x 33.4mm L | TOR |
| 3. | 2831297 | [2] | FLANGE BOLT,Hex, M10 x 1.25 x 52mm, Cl 10.9 | TORM10x1.25x52mm |
| 4. | 4892714 | [4] | BEARING LINER | TORBEARING, CON. ROD |
| 4. | 4892715 | [4] | BEARING LINER | TORBEARING, CON. ROD |
| 5. | REF | [1] | INSTRUCTION | NHPiston -- See Figure 09-19 |
| 6. | REF | [1] | INSTRUCTION | NHCrankshaft -- See Figure 09-17 |
