神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (09-27[00]) - PIPING - ENGINE OIL (101570930002) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
989 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4895164 | [2] | SCREW,Hex, Flg Hd, M6 x 16 | TORM06x1.0x16mm |
| 2. | 4895107 | [1] | HYD CONNECTOR,11/16"-16 x M12 | TOR(Incls. O-Rings 4899107 & 4899108) Superseded by part number: |
| 3. | 4899107 | [1] | O-RING,1.8mm Thk x 10.52mm ID | TOR(Part of 4895107) |
| 4. | 4899108 | [1] | O-RING,0.364mm ID x 0.07mm Width | TOR(Part of 4895107) Superseded by part number: 17277981 |
| 5. | 4899467 | [1] | GASKET | TOR |
| 6. | 4899519 | [1] | CLAMP,M16, M6 Bolt | TOR |
| 7. | 4899106 | [1] | HYD CONNECTOR,11/16" - 16 ORFS x M10 x 1.25 ORB | TOR(Incls. O-Ring 4899108 & Seal 4899121) |
| 8. | 4899108 | [1] | O-RING,0.364mm ID x 0.07mm Width | TOR(Part of 4899106) Superseded by part number: 17277981 |
| 9. | 4899106 | [1] | HYD CONNECTOR,11/16" - 16 ORFS x M10 x 1.25 ORB | TOR(Part of 4899106) |
| 10. | 2853124 | [1] | RIGID TUBE | TOR |
| 11. | 2853120 | [1] | RIGID TUBE | TOR(Incls. O-Ring 4899058) Superseded by part number: |
| 12. | 4899058 | [2] | O-RING,0.674" ID x 0.88" OD x 0.103" | TOR(Part of 2853120) Superseded by part number: 17281881 |
| 13. | 4899068 | [1] | BOLT,Flng, M8 x 1.25 x 16mm | BASM08x1.25x16mm |
| 14. | 2852101 | [1] | FLANGE BOLT,Hex, M6 x 16mm | TORM06x1.0x16mm Superseded by part number: 18137825 |
| 15. | 2852196 | [1] | BRACKET | TOR Superseded by part number: 504053894 |
