卡特零件查询（735） 200-0148: GUARD GP-HYDRAULIC TANK
广数供应链运营团队, 15 02月, 2025，浏览：
445 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 185-5698 | [1] | HINGE AS | |
| 2. | 185-5700 | [1] | HINGE AS | |
| 3. | 187-4278 | [1] | COVER AS | |
| 4. | 187-6156 | [4] | LATCH AS | |
| 5. | 192-1201 | [2] | PLATE-TREAD | |
| 6. | 200-0142 | [1] | COVER AS | |
| | 8T-3490M | [7] | NUT-WELD(M10X1.5-THD) | |
| 7. | 200-0144 | [1] | COVER AS | |
| 8. | 200-0147 | [1] | COVER AS | |
| 9. | 200-1807 | [1] | PLATE-COVER | |
| 10. | 200-2990 | [1] | COVER AS | |
| | 8T-3490M | [4] | NUT-WELD(M10X1.5-THD) | |
| 11. | 201-1379B | [4] | SHIM(1-MM THK) | |
| 12. | 201-4108 | [1] | BAR | |
| 13. | 201-5492 | [1] | CLIP | |
| 14. | 201-5493 | [1] | WASHER-RETAINING(PUSH ON) | |
| 15. | 203-5393 | [1] | STRUT-GAS | |
| 16. | 5C-7261M | [22] | NUT(M8X1.25-THD) | |
| 17. | 7X-0578 | [3] | WASHER-HARD(10.2X32X2.5-MM THK) | |
| 18. | 7X-7729 | [12] | WASHER(11X25X3-MM THK) | |
| 19. | 8C-8585M | [12] | SCREW-BUTTON HEAD(M10X1.5X20-MM) | |
| 20. | 8T-4136M | [3] | BOLT(M10X1.5X25-MM) | |
| 21. | 8T-4189M | [22] | BOLT(M8X1.25X20-MM) | |
| 22. | 8T-4224 | [44] | WASHER-HARD(8.8X16X2-MM THK) | |
| | B | | USE AS REQUIRED |
| | M | | METRIC PART |
