久保田零件查询T02300 AXLE CASE REAR AXLE/REAR WHEELEPC Kubota online
广数供应链运营团队, 15 02月, 2025，浏览：
843 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 001. |
6711112612
|
[1] |
HOLDER DIFF BRG.LH
|
1.3200(lbs); 0.600
|
| 002. |
6711112623
|
[1] |
HOLDER DIFF BRG.RH
|
2.2000(lbs); 1.000
|
| 003. |
0112350825
|
[8] |
BOLT
|
0.0286(lbs); 0.013
|
| 004. |
6780012710
|
[1] |
CASE AXLE LH
|
35.2000(lbs); 16.000
|
| 005. |
6780012720
|
[1] |
CASE AXLE RH
|
35.2000(lbs); 16.000
|
| 006. |
0112351045
|
[6] |
BOLT
|
0.0704(lbs); 0.032
|
| 007. |
0112351035
|
[10] |
BOLT
|
0.0550(lbs); 0.025
|
| 008. |
0451250100
|
[4] |
WASHER SPRING
|
0.0066(lbs); 0.003
|
| 009. |
0501200818
|
[4] |
PIN STRAIGHT
|
0.0286(lbs); 0.013
|
| 010. |
6711112750
|
[2] |
GASKET
|
0.0000(lbs); 0.000
|
| 011. |
6711112780
|
[1] |
PLATE SPRING
|
0.1650(lbs); 0.075
|
| 012. |
6721111140
|
[8] |
PLUG M12
|
0.0022(lbs); 0.001
|
| 013. |
0211850100
|
[4] |
NUT
|
0.0110(lbs); 0.005
|
| 014. |
6711112660
|
[2] |
SHIM 3
|
0.0022(lbs); 0.001
|
| 015. |
0155451228
|
[4] |
STUD
|
0.0704(lbs); 0.032
|
| 016. |
0155451240
|
[4] |
STUD
|
0.0880(lbs); 0.040
|
