神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (03-07[00]) - UPPER ROLLER ASSEMBLY (YN64D00032F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
1036 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN64D01068F1 | [4] | ROLLER | KOBAssembly Incls. Refs. (1-1) - (1-11) Superseded by part number: YN64D01144F1 |
| 1-1. | 2413N469 | [1] | ROLLER | KOB(Part of YN64D01068F1), Not Shown |
| 1-2. | YN64D01069P1 | [1] | SHAFT | KOBShaft, (Part of YN64D01068F1), Not Shown Superseded by part number: YN64D01144F1 |
| 1-3. | 2418P21176 | [1] | COLLAR | KOB(Part of YN64D01068F1), Not Shown Superseded by part number: 2418P22958 |
| 1-4. | YN64D01038P1 | [1] | PLATE | KOB(Part of YN64D01068F1), Not Shown |
| 1-5. | YN64D01026P1 | [1] | COVER | KOB(Part of YN64D01068F1), Not Shown |
| 1-6. | 2405T852 | [1] | BUSHING,45mm ID x 50mm OD x 50mm L | KOBID 45 x OD 50 x 50mm Long, (Part of YN64D01068F1), Not Shown |
| 1-7. | 2445R361F1 | [1] | SEAL,48mm ID x 68.6mm OD x 27mm Thk | KOB(Part of YN64D01068F1), Not Shown |
| 1-8. | ZD11P06500 | [1] | O-RING | KOBID 64.6 ± 0.57 x OD 75mm, (Part of YN64D01068F1), Not Shown |
| 1-9. | YN64D01016P1 | [2] | BOLT | KOBM12x1.75x28mm, (Part of YN64D01068F1), Not Shown |
| 1-10. | ZE82T04000 | [1] | PLUG | KOB1/4" PT, (Part of YN64D01068F1), Not Shown |
| 1-11. | ZR26X07500 | [1] | RING | KOBRetaining -- ID 75 x OD 79.5 x Th 2.5mm, (Part of YN64D01068F1), Not Shown |
| 2. | YN52F01100D3 | [4] | CAP | KOBScrew -- M20x2.50x100mm |
| 3. | ZN13C20016 | [4] | NUT | KOBM20x2.50mm |
| 4. | ZW13H20000 | [4] | WASHER | KOBID 20 x OD 40 x Th 4.5mm |
