神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (03-07[01]) - UPPER ROLLER, ASSY (USED AFTER FEB 2013) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
256 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN64D01144F1 | [1] | ROLLER | KOBAssembly, Incl 2 - 13, Start Year: 01-MAR-13 |
| 2. | YN64D01136P1 | [1] | SHAFT | KOB |
| 3. | YN64D01137P1 | [1] | COLLAR | KOB |
| 4. | YN64D01138P1 | [1] | PLATE | KOB |
| 5. | YN64D01143P1 | [1] | COVER | KOB |
| 6. | YN64D01140P1 | [1] | BUSHING | KOB |
| 7. | YN64D01141P1 | [1] | BUSHING | KOB |
| 8. | 2445R361F1 | [1] | SEAL,48mm ID x 68.6mm OD x 27mm Thk | KOB |
| 9. | ZD11P06500 | [1] | O-RING | KOB |
| 10. | YN64D01016P1 | [2] | BOLT | KOB |
| 11. | YN55V01090P1 | [1] | PLUG | SM |
| 12. | ZR26X07500 | [1] | RING | KOB |
| 13. | YN64D01135P1 | [1] | ROLLER | KOB Superseded by part number: YN64D01144F1 |
