神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (02-06[00]) - RADIATOR ASSEMBLY (YM05P00020F1 & YM05P00020F2) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
228 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM05P00020F1 | [1] | RADIATOR | SMUsed from date 12/01/2006 - 05/21/2008 Superseded by part number: YM05P00020F4 |
| . . | YM05P00020F2 | [1] | RADIATOR | SMUsed after date 05/21/2008 Superseded by part number: YM05P00020F4 |
| 1. | YM05P00019S001 | [1] | RADIATOR | SMAssembly |
| 2. | YN05P00010S006 | [1] | RADIATOR CAP | KOBRadiator Superseded by part number: YN05P00088S032 |
| 3. | 2452U221S18 | [1] | DRAINCOCK/TAP SUPPLY | KOB |
| 4. | 2452U416S6 | [1] | HOSE | KOB |
| 5. | YB05P00001S022 | [2] | INSULATING PANEL | KOB |
| 6. | YM05P00019S006 | [1] | RADIATOR | SMCooler, Oil |
| 7. | YM05P00019S007 | [2] | INSULATOR | SM |
| 8. | YN05P00062S014 | [2] | INSULATOR | SM |
| 9. | YN05P00058S003 | [1] | COOLER | SMCooler, Air |
| 10. | YN05P00058S022 | [1] | INSULATOR | SM |
| 11. | YM05P00019S011 | [1] | SUPPORT | SM(F1 Only) Superseded by part number: YM05P00019S028 |
| . . | YM05P00019S028 | [1] | SUPPORT | SMSupport (F2 Only) |
| 12. | YM05P00019S012 | [2] | INSULATOR | SM |
| 13. | YN05P00058S019 | [2] | INSULATOR | SM |
| 14. | YN05P00062S013 | [2] | INSULATOR | SM |
| 15. | YM05P00020S015 | [1] | GUARD | SMShroud |
| 16. | YM05P00019S016 | [2] | GASKET | SMRubber |
| 17. | YM05P00019S017 | [1] | GUARD | SM |
| 18. | YM05P00019S018 | [1] | GUARD | SM |
| 19. | GB05P00001S006 | [1] | HOSE,25.4mm ID x 2000mm L | KOB |
| 20. | 2452U267S8 | [2] | CLIP | KOB |
| 21. | YM05P00019S021 | [4] | COLLAR | SM |
| 22. | YN05P00058S013 | [4] | SEAT CUSHION | SMMount, Rubber |
| 23. | YN05P00058S014 | [4] | SEAT CUSHION | KOBMount, Rubber |
| 24. | LS05P00009S025 | [4] | SCREW | KOB Superseded by part number: ZM73C10030 |
| 25. | 2452U377S6 | [17] | CAP | KOBScrew -- M06x1.0x112mm |
| 26. | 2452U202S5 | [4] | BOLT | KOBM06x1.0 |
| 27. | YM05P00020S027 | [1] | GUARD | SM |
| 28. | 2452U377S6 | [13] | CAP | KOBScrew -- M06x1.0x112mm |
| 29. | YN05P00058S032 | [1] | GASKET | SMGasket, Rubber (F2 Only), Not Shown |
