神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (02-07[00]) - RADIATOR GROUP (YB05P00006F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
1010 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN05P01041F1 | [1] | TANK | KOBIncls. Refs. 1 - 3 |
| 1. | YN05P01041S1 | [1] | TANK | KOB |
| 2. | YN05P01041S002 | [1] | CAP ASSY. | KOB |
| 3. | 2427U203S6 | [1] | SWITCH | KOBRadiator Over Flow Level |
| 4. | YB05P01166P1 | [1] | RADIATOR HOSE | KOBUpper Superseded by part number: 87606376 |
| 5. | YB05P01164P1 | [1] | RADIATOR HOSE | KOBLower Superseded by part number: 87606365 |
| 6. | YM05P01028P1 | [1] | RADIATOR HOSE | KOB |
| 7. | YB05P01021P1 | [1] | RADIATOR HOSE | KOB |
| 8. | HX11Y05068DX | [1] | TUBE,8mm ID x 680mm L | KOBID 08 x OD 12 x 680mm |
| 9. | YB05P01024P1 | [1] | TUBE,398, 360 mm L | KOB360mm Long (14-11/64 in) |
| 10. | YB05P01165P1 | [1] | RADIATOR HOSE | KOB Superseded by part number: 87606377 |
| 11. | YB05P01109P1 | [1] | PLATE ASSY. | KOB |
| 12. | ZS18C10060 | [2] | SCREW,Hex, M10 x 60mm | KOBM10x1.50x60mm |
| 18. | ZS18C08020 | [4] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 19. | ZS18C10025 | [3] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 20. | ZW16H10000 | [12] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 21. | ZW16X08000 | [4] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 22. | YB05P01167D4 | [1] | CLAMP | KOBClamp Superseded by part number: 71431617 |
| 24. | YB05P01167D3 | [14] | CLAMP | KOB Superseded by part number: 71464956 |
| 26. | YB05P01167D7 | [1] | CLAMP | KOB |
| 28. | YN03E01001D5 | [2] | CLIP | KOB195mm Long (7-43/64 in) -- Black |
| 29. | PH05P01088D4 | [6] | CLIP | KOBClamp, Hose -- Min 12.5 x Max 15mm |
| 30. | PY01P01043D8 | [1] | CABLE TIE,102mm L | KOBWire Ties -- 368mm Long |
| 31. | YB05P01108P1 | [2] | CLIP | KOB Superseded by part number: 87301362 |
| 32. | YM05P01105P1 | [1] | CLIP | KOB Superseded by part number: 87547970 |
| 33. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
