神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (02-10[00]) - MUFFLER ASSEMBLY (YM12P00009F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
859 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM12P00010P1 | [1] | MUFFLER | KOB Superseded by part number: 87345392 |
| 2. | YM12P01009P1 | [1] | TUBE,64 mm ID x 70 mm OD x 147 mm L | KOBExhaust Superseded by part number: 72204761 |
| 3. | YM12P01018P1 | [1] | BRACKET | KOB |
| 4. | YN12P01074P1 | [1] | CLAMP | KOB |
| 5. | YM12P01014P1 | [2] | U-BOLT | KOB |
| 6. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 7. | ZN18C10008 | [2] | NUT | KOBM10x1.50mm |
| 8. | HN18F10000G2 | [8] | NUT | KOBM10x1.25mm |
| 9. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 10. | HX11Y07086DX | [1] | HOSE | KOBID 11 x OD 12 x 860mm Superseded by part number: HX11Y07100DX |
| 11. | ZC16X01200 | [1] | CLIP,8mm - 15mm | KOBClamp, Hose -- Min 08 x Max 15mm |
| 12. | YN12P01075P1 | [1] | CLAMP | KOBID 81.8mm Superseded by part number: YW12PU1004D1 |
| K. | 71503585 | [1] | Kit, Muffler Assembly -- Incls. Refs. 1 & 2 | |
