神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (02-26[00]) - CONTROL, OPERATORS (YN03M00137F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
621 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN03M01859P2 | [2] | SUPPORT | SM |
| 2. | YN26M00065P1 | [1] | FOOT BOARD | SM |
| 3. | YN03M01943F2 | [1] | COVER ASSY | KOB |
| 4. | YN03M01945F1 | [1] | GUARD | SM |
| 5. | YN03M01946F1 | [1] | GUARD | SM |
| 6. | YN25M01168P1 | [1] | SUPPORT | SM |
| 7. | YN25M01161F1 | [1] | GUIDE | SM |
| 8. | YN20M01356P1 | [1] | DIFFUSER | KOB |
| 9. | ZM73C10020 | [4] | BOLT,M10x20mm - Course Thread | KOBM10x1.50x20mm (Incls. Washer) |
| 10. | ZS28C08016 | [4] | SCREW,Hex Socket Head, M8 x 16mm | KOBM08x1.25x16mm |
| 11. | ZW26K08000 | [4] | LOCK WASHER | KOBID 08 x OD 13 x Th 2.0mm |
| 12. | ZW16P08000 | [4] | WASHER | KOBID 8 x OD 17 x Th 1.6mm |
| 13. | ZS28C08020 | [4] | SCREW,Hex Socket Head, M8 x 20mm | KOBM08x1.25x20mm |
| 14. | ZM66C06016 | [9] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 15. | ZM73C08025 | [4] | BOLT,M8x25mm - Course Thread | KOBM08x1.25x25mm (Incls. Washer) |
| 16. | YN20M01643P1 | [1] | SPRING | SM Superseded by part number: YN20M01643P2 |
| 17. | YN02C02055P1 | [1] | TRAY | KOBAsh |
