神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (02-59-03[00]) - TOOL BOX ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
1024 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN21C03848P1 | [1] | PANEL ASSY. | KOB Superseded by part number: 87619048 |
| 2. | YM21C00017P1 | [1] | TOOL BOX | KOBAssembly not serviced -- Order individual parts |
| 3. | YN21C03741P1 | [1] | BRACKET | KOB |
| 4. | YN21C03743P1 | [1] | RUBBER SEAL | KOB Superseded by part number: 87560623 |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONInsulator |
| 6. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOB |
| 7. | ZW16H10000 | [2] | WASHER | KOB |
| 8. | ZN18C10008 | [4] | NUT | KOB |
| 9. | 2418T12346 | [4] | WASHER | KOB |
| 10. | YJ21C01079D6 | [3] | INSULATING PANEL | KOB |
| 11. | NSS | [2] | NOT SOLD SEPARAT | CON |
