神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (02-63[00]) - CONTROLLER INSTAL (YM22E00020F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
979 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN22E01258P3 | [1] | SUPPORT | KOB |
| 2. | YN50S00047P1 | [1] | TOGGLE SWITCH | KOBAssembly, Toggle (Swing Parking Brake Release) |
| 3. | YN22M01014P1 | [1] | LABEL | KOBDecal, Swing Parking Brake Release Lock and Normal |
| 4. | ZM73C08020 | [4] | BOLT,M8x20mm - Course Thread | KOBM08x1.25x20mm (Incls. Washer) |
| 5. | ZM61C06025 | [7] | BOLT | KOBM06x1.0x25mm (Incls. Washer & Lockwasher) |
| 6. | ZM41C03008 | [4] | BOLT | KOBM03x0.5x08mm (Incls. Washer & Lockwasher) |
| 7. | ZM61C04012 | [1] | BOLT | KOBM04x0.7x12mm (Incls. Washer & Lockwasher) |
| 8. | LC22E01001D1 | [1] | RESISTOR,16ohm | KOB16 Ohm |
| 9. | YX50S00001F1 | [1] | TOGGLE SWITCH | SMAssembly, Toggle Superseded by part number: YX50S00004F1 |
| 10. | YV22E01002P1 | [1] | LABEL | KOBDecal, KPSS/Release |
| 11. | ZM61C05016 | [2] | BOLT | KOBM05x0.8x16mm (Incls. Washer & Lockwasher) |
| 12. | YN77S00017P1 | [1] | CONVERTER,24V In - 13.2V Out - 7.5A | KOB Superseded by part number: YN77S00069P1 |
| 13. | YM22E00018F1 | [1] | ECU | SMController Assembly If Used YM22E00023F1 (Date 09/01/06 - 05/28/07) Superseded by part number: YM22E00018F4 |
| 14. | YM22E00023F1 | [1] | CONTROL UNIT | KOBController Assembly If Used YM22E00018F1 (Date 05/28/07 - Up) Superseded by part number: YM22E00023F5 |
| 15. | YN24E00022F1 | [1] | RELAY | KOBBox Assembly (See Figure 02-64) (Incls. Refs. 16 - 18) |
| 16. | NSS | [1] | NOT SOLD SEPARAT | CONRelay Box Assembly, (Part of YN24E00022F1) |
| 17. | YN73E01026P2 | [1] | DATA PLAQUE | KOBDecal, Caution: Use Designated Fuse and Relay Only. -- (Part of YN24E00022F1) |
| 18. | YN24S00010P1 | [1] | RELAY | KOB(Part of YN24E00022F1) |
