神钢零件查询(SK170-8) - ACERA MARK III EXCAVATOR - TIER 3 (NA) ASN YM04-U1601 - (5/07-12/12) (02-62-00[00]) - GAUGE ASSEMBLY, CLUSTER (YN59S00021F2) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
773 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN59S00021F2 | [1] | GAUGE | KOBCluster, Incls. Refs. 1 - 10 Superseded by part number: YN59S00021F3 |
| 1. | YN59S00021S001 | [1] | CONTROL MONITOR | SM |
| 2. | YN59S00021S002 | [1] | PRINTED CIRCUIT BOAR | SM |
| 3. | YN59S00021S003 | [1] | COVER | SM |
| 4. | YN59S00021S004 | [1] | COVER | SM |
| 5. | YN59S00021S005 | [1] | BUZZER | SM |
| 6. | YN59S00021S006 | [1] | PANEL | SM |
| 7. | YN59S00021S007 | [6] | SCREW | SM |
| 8. | YN59S00021S008 | [6] | SCREW | SM |
| 9. | YN59S00021S009 | [2] | SCREW | SM |
| 10. | YN59S00021S010 | [7] | SCREW | SM |
