卡特零件查询（735） 191-8186: FRAME GP-REAR
广数供应链运营团队, 15 02月, 2025，浏览：
630 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 3U-9058 | [7] | SPACER(42-MM THK) | |
| 2. | 141-6868 | [1] | FRAME AS | |
| | 7T-1099 | [10] | LINK | |
| | 8Y-3925M | [2] | BOSS(M10X1.5X30-MM) | |
| 3. | 175-5899 | [4] | BUSHING | |
| 4. | 188-1822 | [1] | SUPPORT AS(RH) | |
| 5. | 188-1828 | [1] | SUPPORT AS(LH) | |
| 6. | 189-1541 | [1] | PLATE AS | |
| 7. | 189-4235 | [2] | PLATE AS | |
| 8. | 199-6967 | [1] | PLATE | |
| 9. | 217-6282 | [1] | PLATE AS | |
| | 8T-3490M | [2] | NUT-WELD(M10X1.5-THD) | |
| 10. | 131-5879 | [4] | WASHER(11X32X3-MM THK) | |
| 11. | 7X-2553M | [8] | BOLT(M16X2X40-MM) | |
| 12. | 7X-2563M | [12] | BOLT(M20X2.5X60-MM) | |
| 13. | 8T-4123 | [19] | WASHER(3.62X5.75X0.375-MM THK) | |
| 14. | 8T-4136M | [2] | BOLT(M10X1.5X25-MM) | |
| 15. | 8T-4187M | [7] | BOLT(M20X2.5X80-MM) | |
| 16. | 9X-8257 | [8] | WASHER(17.5X30X3.5-MM THK) | |
| | M | | METRIC PART |
