卡特零件查询（735） 20R-3283: KIT-ENGINE OVERHAUL
广数供应链运营团队, 15 02月, 2025，浏览：
860 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| | 443-7600Y | [1] | KIT-ENGINE OVERHAUL(BRONZE) | |
| | 10R-6007 | [6] | CYLINDER PACK GP | |
| | | | (EACH INCLUDES) |
| | 247-6130 | [1] | RING-PISTON-TOP | |
| | 306-4014 | [1] | RING-PISTON(OIL) | |
| | 180-7350 | [1] | PIN-PISTON | |
| | 10R-2117 | [1] | ROD AS-CONNECTING | |
| | 7N-2043 | [2] | DOWEL | |
| | 213-3217M | [4] | BOLT(M11X1.25X84-MM) | |
| | 229-6259 | [1] | BEARING | |
| | 160-9874Y | [1] | KIT-GASKET(SINGLE CYLINDER LINER) | |
| | 164-4187 | [1] | RING-PISTON(INTERMEDIATE) | |
| | 197-9322 | [1] | LINER-CYLINDER BLOCK | |
| | 230-2569 | [2] | RETAINER-PIN | |
| | | | |
| | | | FOR A LIST OF RELATED PARTS THAT REQUIRED FOR THE ENGINE REBUILD TO THE KIT CONSIST, PLEASE VISIT |
| | | | |
| | | | HTTPS://DEALER.CAT.COM/RELATED |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
