卡特零件查询（735） 20R-3290: KIT-ENGINE OVERHAUL
广数供应链运营团队, 15 02月, 2025，浏览：
862 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| | 443-7600Y | [1] | KIT-ENGINE OVERHAUL(BRONZE) | |
| | 20R-2647 | [1] | CYLINDER HEAD GP | |
| | 186-2001 | [24] | ROTOCOIL AS | |
| | 211-3122 | [24] | SPRING-VALVE | |
| | 214-7568 | [5] | SEAL-O-RING | |
| | 223-7263Y | [1] | CYLINDER HEAD AS | |
| | 247-9908 | [24] | SPRING-VALVE(OUTER) | |
| | | [1] | BRIDGE-VALVE |
| | 348-7743 | [12] | BRIDGE-VALVE | |
| | 236-5605 | [12] | VALVE-INLET | |
| | 9S-8004 | [4] | PLUG(9/16-18-THD) | |
| | 9S-8005 | [2] | PLUG(3/4-16-THD) | |
| | 9S-8006 | [1] | PLUG(7/8-14-THD) | |
| | 153-7024 | [12] | VALVE-EXHAUST | |
| | 163-2478 | [24] | SEAL-VALVE STEM | |
| | 2A-4429 | [48] | LOCK-RETAINER | |
| | 2R-6806 | [1] | CONNECTOR | |
| | 6I-0928 | [24] | WASHER-SPECIAL | |
| | 6V-3251 | [1] | SEAL-O-RING | |
| | 6V-6609 | [2] | SEAL-O-RING | |
| | 10R-6007 | [6] | CYLINDER PACK GP | |
| | | | (EACH INCLUDES) |
| | 247-6130 | [1] | RING-PISTON-TOP | |
| | 306-4014 | [1] | RING-PISTON(OIL) | |
| | 180-7350 | [1] | PIN-PISTON | |
| | 10R-2117 | [1] | ROD AS-CONNECTING | |
| | 7N-2043 | [2] | DOWEL | |
| | 213-3217M | [4] | BOLT(M11X1.25X84-MM) | |
| | 229-6259 | [1] | BEARING | |
| | 160-9874Y | [1] | KIT-GASKET(SINGLE CYLINDER LINER) | |
| | 164-4187 | [1] | RING-PISTON(INTERMEDIATE) | |
| | 197-9322 | [1] | LINER-CYLINDER BLOCK | |
| | 230-2569 | [2] | RETAINER-PIN | |
| | 20R-2284 | [6] | INJECTOR GP-FUEL | |
| | | | (EACH INCLUDES) |
| | 100-7965 | [1] | PIN-STOP | |
| | 230-3728 | [1] | SEAL-O-RING | |
| | 230-3775 | [1] | SEAL-O-RING | |
| | 3E-4354 | [1] | BALL | |
| | 4N-9019 | [4] | DOWEL | |
| | 9X-7317 | [1] | SEAL-O-RING | |
| | 100-6165 | [1] | SPRING-NOZZLE | |
| | 0R-9449Y | [1] | PUMP GP-ENGINE OIL | |
| | 10R-8660 | [1] | PUMP GP-WATER | |
| | 299-7436Y | [1] | KIT-GASKET(WATER PUMP) | |
| | | [1] | PUMP GP-WATER |
| | 336-2212 | [1] | SEAL AS-WATER PUMP | |
| | 136-1107 | [1] | RETAINER | |
| | 153-1256 | [1] | SEAL-LIP TYPE | |
| | 195-0319 | [1] | GEAR(74-TEETH) | |
| | 203-3831 | [1] | PLUG-CUP | |
| | 246-3130 | [1] | SHAFT-WATER PUMP | |
| | 108-7930 | [1] | BEARING AS-ROLLER | |
| | 1B-7182 | [4] | BOLT(5/16-18X1.25-IN) | |
| | 246-3129 | [1] | IMPELLER-PUMP | |
| | 303-8698 | [1] | HOUSING AS-PUMP | |
| | 111-2721 | [1] | PLUG-FELT | |
| | | | |
| | | | FOR A LIST OF RELATED PARTS THAT REQUIRED FOR THE ENGINE REBUILD TO THE KIT CONSIST, PLEASE VISIT |
| | | | |
| | | | HTTPS://DEALER.CAT.COM/RELATED |
| | | | |
| | | | AVAILABLE REPAIR KIT(S): |
| | 349-2653AB | [1] | KIT-CYLINDER HEAD | |
| | | | (INCLUDES CYLINDER HEAD GROUP & BRIDGES) |
| | A | | NOT PART OF THIS GROUP |
| | B | | USE AS REQUIRED |
| | M | | METRIC PART |
| | R | | REMANUFACTURED PART MAY BE AVAILABLE |
| | Y | | SEPARATE ILLUSTRATION |
