久保田零件查询K13000 MOWER REAR LINK RH TOP LINK/TOP LINK BRACKET/PTO PROTECTOREPC Kubota online
广数供应链运营团队, 15 02月, 2025，浏览：
263 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
K256144114
|
[1] |
LINK COMP 3P MOWER
|
3.1020(lbs); 1.410
|
| 020. |
0113351235
|
[2] |
BOLT
|
0.0946(lbs); 0.043
|
| 030. |
K251144250
|
[1] |
SHAFT REAR LIFT LINK
|
3.9380(lbs); 1.790
|
| 040. |
K256144204
|
[1] |
LINK REAR LIFT RH
|
3.4540(lbs); 1.570
|
| 040. |
K256144205
|
[1] |
LINK REAR LIFT RH
|
3.4540(lbs); 1.570
|
| 050. |
K256143180
|
[1] |
BUSH
|
0.2178(lbs); 0.099
|
| 060. |
7559951440
|
[1] |
PIN CLEVIS
|
0.0968(lbs); 0.044
|
| 070. |
7559932014
|
[1] |
WASHER PLAIN
|
0.0110(lbs); 0.005
|
| 070. |
0Y40150070
|
[1] |
WASHER PLAIN
|
0.0946(lbs); 0.043
|
| 080. |
7559953173
|
[1] |
PIN COTTER
|
0.0044(lbs); 0.002
|
| 090. |
K256144180
|
[1] |
COLLAR MOWER ADJUST
|
0.0506(lbs); 0.023
|
| 100. |
0217450120
|
[2] |
NUT
|
0.0220(lbs); 0.010
|
| 110. |
K256144270
|
[1] |
LINK LIFT UPPER
|
0.5720(lbs); 0.260
|
| 120. |
K256144280
|
[1] |
LINK LIFT LOWER
|
0.5940(lbs); 0.270
|
| 130. |
K251144310
|
[1] |
LINK REAR
|
4.0700(lbs); 1.850
|
| 140. |
K121191690
|
[1] |
BOLT SHORT SQU.NECK
|
0.2420(lbs); 0.110
|
| 150. |
K121191930
|
[1] |
NUT
|
0.0660(lbs); 0.030
|
| 160. |
7559951535
|
[1] |
PIN CLEVIS
|
0.1056(lbs); 0.048
|
| 170. |
K514272730
|
[1] |
RING SNAP
|
0.0066(lbs); 0.003
|
| 180. |
7559952532
|
[1] |
PIN SPRING
|
0.0110(lbs); 0.005
|
| 190. |
K565144650
|
[1] |
PIN REAR
|
0.4400(lbs); 0.200
|
| 200. |
K565144670
|
[1] |
SPRING PIN
|
0.4620(lbs); 0.210
|
